2025 TYM T494H
2025 TYM T494H - Image 2
2025 TYM T494H - Image 3
2025 TYM T494H - Image 4
2025 TYM T494H - Image 5
2025 TYM T494H - Image 6
2025 TYM T494H - Image 7
2025 TYM T494H - Image 8

2025 TYM T494H

Call For Pricing

FREE DELIVERY WITHIN 60 MILES OF WAKARUSA,INDIANA WITH THE PURCHASE OF A NEW TRACTOR!!!!!
Engine: TYM A2300N2, 4-cylinder, naturally aspirated diesel

Gross Engine Power: 48.3 hp

PTO Power: 34.2–37.2 hp (varies by configuration)

Displacement: 2,197 cc (134 cu. in.)

Rated Engine Speed: 2,600 rpm

Fuel Tank Capacity: 17.0 gallons

Transmission: 3-range Hydrostatic (HST)

Drive: 4WD (MFWD)

Brakes: Wet disc

Steering: Hydrostatic
SOUTHERN FARM EQUIPMENT
+7
Hydraulic Pump Type: Open center

Implement Flow: 7.66 gpm

Steering Flow: 4.25 gpm

Total Hydraulic Flow: 11.91 gpm

3-Point Hitch Category: I

Lift Capacity at Link Ends: 3,822 lbs

Lift Capacity at 24″ Behind Link Ends: 3,057 lbs

PTO Type: Independent, wet multi-disc

Rear PTO Speed: 540 rpm
Overall Length (with 3-point hitch): 141.3 in.

Overall Width: 63.8 in.

Wheelbase: 76.2 in.

Height to Top of ROPS: 102.1 in.

Minimum Ground Clearance: 13.8 in.

Turning Radius with Brakes: 121.2 in.

Weight with ROPS: 3,871 lbs
X57 Front-End Loader: Lifts up to 2,790 lbs at the pivot pins with a maximum height of 109.4 in.

Skid Steer Style Quick Attach Bucket: 72 in. width, 11.3 cu. ft capacity

Backhoe Attachment (BY85): Optional, with a max dig depth of 103.2 in. and a bucket digging force of 4,435 lbs

Operator Comfort: Fully adjustable suspension seat, tilt steering wheel, and optional cab with air conditioning and heating

Additional Features: Two rear remote hydraulic valves, foldable ROPS, cruise control, and joystick-controlled SCV

SKU: dac54ff6815f Categories: ,

Description

FREE DELIVERY WITHIN 60 MILES OF WAKARUSA,INDIANA WITH THE PURCHASE OF A NEW TRACTOR!!!!!
Engine: TYM A2300N2, 4-cylinder, naturally aspirated diesel

Gross Engine Power: 48.3 hp

PTO Power: 34.2–37.2 hp (varies by configuration)

Displacement: 2,197 cc (134 cu. in.)

Rated Engine Speed: 2,600 rpm

Fuel Tank Capacity: 17.0 gallons

Transmission: 3-range Hydrostatic (HST)

Drive: 4WD (MFWD)

Brakes: Wet disc

Steering: Hydrostatic
SOUTHERN FARM EQUIPMENT
+7
Hydraulic Pump Type: Open center

Implement Flow: 7.66 gpm

Steering Flow: 4.25 gpm

Total Hydraulic Flow: 11.91 gpm

3-Point Hitch Category: I

Lift Capacity at Link Ends: 3,822 lbs

Lift Capacity at 24″ Behind Link Ends: 3,057 lbs

PTO Type: Independent, wet multi-disc

Rear PTO Speed: 540 rpm
Overall Length (with 3-point hitch): 141.3 in.

Overall Width: 63.8 in.

Wheelbase: 76.2 in.

Height to Top of ROPS: 102.1 in.

Minimum Ground Clearance: 13.8 in.

Turning Radius with Brakes: 121.2 in.

Weight with ROPS: 3,871 lbs
X57 Front-End Loader: Lifts up to 2,790 lbs at the pivot pins with a maximum height of 109.4 in.

Skid Steer Style Quick Attach Bucket: 72 in. width, 11.3 cu. ft capacity

Backhoe Attachment (BY85): Optional, with a max dig depth of 103.2 in. and a bucket digging force of 4,435 lbs

Operator Comfort: Fully adjustable suspension seat, tilt steering wheel, and optional cab with air conditioning and heating

Additional Features: Two rear remote hydraulic valves, foldable ROPS, cruise control, and joystick-controlled SCV
